Location Width Length Height Processor 1 Processor 2
Riser 2A Riser 2A Riser 3A
PCIe Slot-3 SW HL LP - x16
● Riser configuration 3: R1A + R4C + R4D
Location Width Length Height Processor 1 Processor 2
Riser 2A Riser 4C Riser 4D
PCIe Slot-1 SW 3/4L FH x16 -
PCIe Slot-2 SW 3/4L FH - x16
The VxRail E660N supports the following riser configuration:
Table 1. Riser configuration 4: R2A + R3A + R1D Paddle card
Location Width Length Height Processor 1 Processor 2
Riser 2A Riser 2A Riser 3A
PCIe Slot-1 SW HL LP x16 - -
PCIe Slot-2 SW HL LP - x16 -
PCIe Slot-3 SW HL LP - x16
