Dell W29C - System-Board Shield; Removing the System-Board Shield

Steps
1. Align the screw holes on the stand hinges with the screw holes on the display-assembly base.
2. Replace the 10 screws (M3x4.5) that secure the stand hinges to the display-assembly base.
Next steps
1. Install the I/O cover.
2. Install the back cover.
3. Install the stand.
4. Follow the procedure in After working inside your computer.
System-board shield
Removing the system-board shield
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the stand.
3. Remove the back cover.
4. Remove the I/O cover.
About this task
The following image indicates the location of the system-board shield and provides a visual representation of the removal
procedure.
