26
| Removing
the
Coin-Cell
Battery
4
Peel the coin-cell battery off the keyboard.
5
Lift the coin-cell battery along with its cable off
the keyboard.
1
coin-cell-battery cab
le
2
coin-cell battery
2
1
book
.boo
k Page
26 Tu
es
day, Octo
ber
23, 20
12 1
2
:4
4 AM
25
27
