Palm-rest and keyboard assembly
Removing the palm-rest and keyboard assembly
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the fan.
5. Remove the display assembly.
6. Remove the I/O daughter-board.
7. Remove the system board.
NOTE: The system board can be removed with the attached heat sink.
About this task
The following image shows the palm-rest and keyboard assembly.
Steps
After performing the steps in the pre-requisites, you are left with the palm-rest and keyboard assembly.
Installing the palm-rest and keyboard assembly
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
NOTE:
The replacement palm-rest and keyboard assembly comes pre-assembled with the following components:
● palm rest
36 Removing and installing components
