5. Press Y to save the changes.
The computer restarts.
Deleting or changing an existing system setup password
Prerequisites
Ensure that the Password Status is Unlocked (in the System Setup) before attempting to delete or change the existing
System and/or Setup password. You cannot delete or change an existing System or Setup password, if the Password Status is
Locked.
About this task
To enter the System Setup, press F12 immediately after a power-on or reboot.
Steps
1. In the System BIOS or System Setup screen, select System Security and press Enter.
The System Security screen is displayed.
2. In the System Security screen, verify that Password Status is Unlocked.
3. Select System Password, update, or delete the existing system password, and press Enter or Tab.
4. Select Setup Password, update, or delete the existing setup password, and press Enter or Tab.
NOTE: If you change the System and/or Setup password, reenter the new password when prompted. If you delete the
System and/or Setup password, confirm the deletion when prompted.
5. Press Esc and a message prompts you to save the changes.
6. Press Y to save the changes and exit from System Setup.
The computer restarts.
Clearing BIOS (System Setup) and System passwords
About this task
To clear the system or BIOS passwords, contact Dell technical support as described at www.dell.com/contactdell.
NOTE:
For information on how to reset Windows or application passwords, refer to the documentation accompanying
Windows or your application.
Updating the BIOS
Updating the BIOS in Windows
Steps
1. Go to www.dell.com/support.
2. Click Product support. In the Search support box, enter the Service Tag of your computer, and then click Search.
NOTE:
If you do not have the Service Tag, use the SupportAssist feature to automatically identify your computer. You
can also use the product ID or manually browse for your computer model.
3. Click Drivers & Downloads. Expand Find drivers.
4. Select the operating system installed on your computer.
5. In the Category drop-down list, select BIOS.
6. Select the latest version of BIOS, and click Download to download the BIOS file for your computer.
7. After the download is complete, browse the folder where you saved the BIOS update file.
8. Double-click the BIOS update file icon and follow the on-screen instructions.
For more information, see knowledge base article 000124211 at www.dell.com/support.
System setup
57

Dell XPS 13 9315 Specifications

General

HD type	3K
Panel type	WVA
Pixel density	267 ppi
Display diagonal	13 \
Display brightness	500 cd/m²
Display resolution	2880 x 1920 pixels
Native aspect ratio	3:2
Anti-reflective coating	Yes
Internal memory	16 GB
Memory clock speed	2133 MHz
Internal memory type	LPDDR4x-SDRAM
Ethernet LAN	No
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Wi-Fi data rate (max)	2400 Mbit/s
WLAN controller manufacturer	Intel
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	2.25 A
AC adapter output voltage	20 V
Battery voltage	11.4 V
Battery capacity	- mAh
Battery recharge time	3 h
Number of battery cells	3
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Rear camera type	Single camera
Video capturing speed	30 fps
Rear camera resolution	3840 x 2160 pixels
Rear camera resolution (numeric)	10 MP
Front camera resolution (numeric)	5 MP
Position location	-
Audio system	Waves MaxxAudio
Speaker power	2 W
Device type	Tablet PC
Form factor	Slate
Product color	Blue
Cables included	AC
Pixel pitch	0.095 x 0.095 mm
Display response rise/fall	35 ms
Processor cache	12 MB
Processor cores	10
Processor family	Intel® Core™ i7
Processor frequency	- GHz
Processor boost frequency	4.7 GHz
SSD interface	M.2, PCI Express
Storage media	SSD
Internal storage capacity	512 GB
Platform	Windows
Trial software	McAFee Livesafe 12 months, No Microsoft Office Included
Operating system language	ENG, ESP, FRE
Operating system installed	Windows 11 Home
Operating system architecture	64-bit
Graphics card	Iris Xe Graphics

Weight and Dimensions

Depth	201.2 mm
Width	292.5 mm
Height	7.4 mm
Weight	740 g
