Back to Contents Page
Technical Overview
Dell™XPS™210ServiceManual
Inside View of Your Computer
System Board Components
Power Supply DC Connector Pin Assignments
Inside View of Your Computer
System Board Components
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before opening the cover.
1
drive release latch
2
CD/DVD drive
3
power supply and fan
4
hard drive
5
heat sink assembly
6
power button
7
front panel door
