Dell XPS 8960 User Manual

NOTE: To achieve dual-channel support when installing two memory modules of the same capacity, install the memory
modules in DIMM 1 and 2 or DIMM 3 and 4.
4. Place the computer in an upright position.
Next steps
1. Install the left-side cover.
2. Follow the procedure in After working inside your computer.
Solid-state drive
Removing the 2230 solid-state drive
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
About this task
NOTE: Depending on the configuration ordered, your computer may have up to two M.2 2230/2280 solid-state drives
installed in the two M.2 solid-state drive slots on the system board.
The following image(s) indicate the location of the 2230 solid-state drive and provides a visual representation of the removal
procedure.
Steps
1. Place the computer on its side with the left side facing up.
2. Remove the screw (M2x3) that secures the 2230 solid-state drive to the system board.
3. Slide and lift the 2230 solid-state drive from the M.2 card slot on the system board.
28
Removing and installing components

Dell XPS 8960 Specifications

General

Processor	13th Gen Intel Core i7
Graphics	NVIDIA GeForce RTX 3060
Memory	Up to 64GB DDR5
Storage	512GB SSD
Operating System	Windows 11 Pro
Wireless	Wi-Fi 6E, Bluetooth
Power Supply	460W
Ports (Front)	USB 3.2 Gen 1 Type-A, USB 3.2 Gen 1 Type-C, Headphone/Microphone combo jack
Ports (Rear)	USB 2.0, USB 3.2 Gen 1, USB 3.2 Gen 2, HDMI, DisplayPort, Ethernet
Expansion Slots	PCIe x16
