Dell XPS 8960 User Manual

Processor
Removing the processor
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
3. Remove the fan and heat-sink assembly (65 W) or the fan and heat-sink assembly (125 W), whichever applicable.
About this task
The following image(s) indicate the location of the processor and provides a visual representation of the removal procedure.
Steps
1. Press the release lever down and then push it away from the processor to release it from the securing tab.
2. Extend the release lever completely and open the processor cover.
CAUTION:
When removing the processor, do not touch any of the pins inside the socket or allow any objects
to fall on the pins in the socket.
3. Gently lift the processor from the processor socket.
Installing the processor
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following image(s) indicate the location of the processor and provides a visual representation of the installation procedure.
54
Removing and installing components

Dell XPS 8960 Specifications

General

Processor	13th Gen Intel Core i7
Graphics	NVIDIA GeForce RTX 3060
Memory	Up to 64GB DDR5
Storage	512GB SSD
Operating System	Windows 11 Pro
Wireless	Wi-Fi 6E, Bluetooth
Power Supply	460W
Ports (Front)	USB 3.2 Gen 1 Type-A, USB 3.2 Gen 1 Type-C, Headphone/Microphone combo jack
Ports (Rear)	USB 2.0, USB 3.2 Gen 1, USB 3.2 Gen 2, HDMI, DisplayPort, Ethernet
Expansion Slots	PCIe x16
