Memory
Dell™ XPS™ M1330 Service Manual
Removing the DIMM 1 Memory Module
Replacing the DIMM 1 Memory Module
Removing the DIMM 2 Memory Module
Replacing the DIMM 2 Memory Module
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
You can increase your computer memory by installing memory modules on the system board. See "Specifications" in your
Owner's Manual for information on the memory supported by your computer. Install only memory modules that are intended
for your computer.
NOTE: Memory modules purchased from Dell are covered under your computer warranty.
Your computer has two user-accessible SODIMM sockets that can be accessed from the bottom of the computer.
NOTICE: If you need to install memory modules in two connectors, install a memory module in the connector labeled
"DIMM1" before you install a module in the connector labeled "DIMM2."
Removing the DIMM 1 Memory Module
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching
an unpainted metal surface (such as a connector on the back of the computer).
NOTICE: If a memory module is installed in the DIMM 2 connector, remove it prior to removing the memory module
from the DIMM 1 connector. Failure to do so could result in damaging both memory modules.
1. Follow the procedures in Before You Begin
.
2. Turn the computer over and loosen the three captive screws along with the M2.5 x 5-mm screw. Remove the module
cover.
