2 Control panel
A
U
T
O
12 45 78910
CONTROL PANEL - Controls description
1. Electronic clock/end cooking timer (main left oven only)
2. Fan main oven thermostat knob
3. Fan main oven switch knob
4. Front left burner control knob
5. Rear left burner control knob
6. Central burner control knob
7. Rear right burner control knob
8. Front right burner control knob
9. Conventional oven switch knob
10. Conventional oven thermostat knob
Pilot lamps:
11. Main oven thermostat indicator light
12. Conventional oven thermostat indicator light
3
11 12
Fig. 2.1
