FITTING THE OVEN INTO A
COLUMN
The cabinet should have the dimen-
sions as per fig. 8.
Furthermore it is necessary that the
oven is provided with a chimney as per
fig. 9.
If the column unit reaches the ceiling
an outlet must be provided through
which air can flow to the outside.
Figure 8
Figure 9
10
WARNING
When correctly installed,
your product meets all safety
requirements laid down for
this type of product category.
However special care should
be taken around the rear or
the underneath of the appli-
ance as these areas are not
designed or intended to be
touched and may contain
sharp or rough edges, that
may cause injury.
