Owner´s Manual DEA601 Radio
36 | P a g e
Figure 72: Open Camera Views App.
Application Interface
The Camera Views App present the view of the 4 cameras installed on the
vehicle one at a time, each of the camera views option work as a softkey.
The system display the camera view corresponding to the soft key selected.
The system present the Reverse view as default once the application is
open.
The application presents the next activation softkeys relative to each of the
available views. Figure 73 as reference.
 Reverse View
 Forward View
 Right View
 Left View
Figure 73: Camera view reference.
This feature may not be available in all vehicles.
The mentioned activation softkeys is presented as part of the standard view
of the activation. The user is able to establish the view as full screen mode
and to return to the standard view mode.
The application indicates the current activated view. The forward camera
image is mirrored (left to right) to provide a correct image.
Automatic Cameras View
The next camera view is activated automatically under certain scenarios:
 Reverse View
 Right View
 Left View
The system activates the Reverse View in case the vehicle is put in reverse
(if the automatic view function is activated).
The system activates the Right View in case the right turning signal is
activated (if the automatic view function is activated).
