Delphi DEA601 User Manual

Owner´s Manual DEA601 Radio
61 | P a g e
Each Audio setting section has a checkbox as selector control. The system
adjusts the Audio output configuration based on the option selected. The
system does not allow selecting more than one Auto Equalization option.
In the case the system detects the selection of the current Auto Equalization
option, no change will take place.
Speed Dependent Volume
This function increases the volume level with speed in order to compensate
engine or road noise and decreased when slow down.
In the case the Speed Dependent Volume option is selected, the system
displays the next configurable options. Figure 123 as reference.
 Off
 Low
 Mid
 High
Figure 123: The System audio screen Part II.
The system allows the selection of one option at a time.
Speakers Configuration
In the case the Speakers configuration option is selected, the system
displays the next configurable options. Figure 123 as reference.
 4 Speakers
 2 Speakers
The system allows the selection of one option at a time.
Seek Sensitivity -6dB to +6dB
The seek sensitivity option is present in a bar selector manner.
The scale of the seek sensitivity Bar is from -6 dB to +6 dB. The system
detects 12 steps on each of the bars. The system adjusts 1 dB per step of
the corresponding value. As illustrated in Figure 124.
Figure 124: Seek sensitivity screen.
Speed Dependant Volume
Speakers Configuration
Off
Low
Mid
High
4 Speakers
2 Speakers
