Pr05-00=6: For IM motor dynamic auto-tuning. You can get the motor parameters
R
s
, R
r
, L
m
, Lx and no-load current and the field weakening flux table.
This is for FOC Sensorless mode.
The motor runs and must be unloaded.
Pr05-00=12: For IM motor inertia auto-tuning in FOC Sensorless.
After finishing Pr05-00=6 auto-tuning, if you want to use Pr11-03, Pr11-04, and Pr11-
05 as ASR, you must set Pr05-00=12 for inertia auto-tuning.
Q How to read parameters from C2000/CP2000 keypad by VFDSoft?
A Connect the keypad via IFD6530.
Press MENU, go to 13. PC-Link, ENTER, select VFDSoft, ENTER.
Select the file you want. Press ENTER.
The display shows Waiting 0%
Now open VFDSoft.
Open Parameter
Select Table: Read from KPC-CC01
