DELTA DORE PACK TYXIA 541 - Connection Instructionsfor Terminals 1 2 3

EN
27
2.1 Connection instructionsfor terminals 1 2 3 4
Strip the wires while respecting
WKHVWULSOHQJWKVSHFLĆHGRQWKH
product.
0,75 - 1,5 mm
Ø
2
• Stranded wires• Solid wires
2
1
Using the tool supplied or a
2.5 mm screwdriver, press the
terminal button then insert
the wire.
Push the wire
fully into
the terminal.
Removal recommendations
- Switch off the power supply.
- Use the tool supplied or a 2.5
mm screwdriver to press the
button of the front terminal
before removing the wire.
2
1
