General| Input Frequency | 50/60 Hz |
|---|---|
| Control Method | V/F control |
| IP Rating | IP20 |
| Humidity | Less than 90% RH (non-condensing) |
| Output Voltage | 0 to Input Voltage |
| Overload Capacity | 150% for 60 seconds |
| Braking Unit | Built-in |
| Protection Functions | Over voltage, Over current, Under voltage, Over temperature, Short circuit |
| Communication | RS-485 (Modbus) |
| Digital Output | 1 (Relay output) |
| Analog Output | 1 (0 to 10 VDC) |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -20°C ~ +60°C |
| Altitude | 1000m (Derating required above 1000m) |
| Input Voltage | 1-phase 200 ~ 240VAC, 3-phase 200 ~ 240VAC, 3-phase 380 ~ 480VAC |
| Output Frequency | 0.1 to 600 Hz |
| Power Range | 0.2 kW ~ 3.7 kW |
| Digital Inputs | 5 programmable digital inputs |
| Analog Input | 2 (0-10V, 4-20mA) |
