Chapter 3 Connections and Wiring|ASDA-A&A+ Series
Revision April 2009 3-3
3) Check if the phase of U, V, W cables is connected correctly. Incorrect connection will cause the
servo motor to rotate improperly.
4) When using an external resistor, connect it to P (P
) and C, and ensure an open circuit between P
(P
) and D. When using an internal resistor, ensure the circuit is closed between P (P ) and D, and
the circuit is open between P (P
) and C.
5) If a fault or emergency stop occurs, using ALARM or WARN output can control electromagnetic
contactor and cut off the power of the servo drive.
