Appendix A Accessories|ASDA-A&A+ Series
A-6
Revision April 2009
Delta Part Number: ASD-CAPW2303, ASD-CAPW2305 (cable for motors with brake)
(for models of 3kW and below)
L
(100 mm)
(3.15 inch)
(3.94 inch)
(80mm)
L
Title Part No. Straight
mm inch
1 ASD-CAPW2303 MS 3106-24-11S
3000 ± 10 118 ± 0.4
2 ASD-CAPW2305 MS 3106-24-11S
5000 ± 10 197 ± 0.4
Power Cables: ASD-CAPW3203, ASD-CAPW3205 (for 4.5kW model)
L L1
Item Part No. Straight
mm inch mm inch
1 ASD-CAPW3203 MS 3106-24-11S
3000 ± 10 118 ± 0.4 3100 ± 10 122 ± 0.4
2 ASD-CAPW3205 MS 3106-24-11S
5000 ± 10 197 ± 0.4 5100 ± 10 201 ± 0.4
