Chapter 3 Connections and Wiring|ASDA-A&A+ Series
3-12 Revision April 2009
ASDA-A+ Series
Power Cable
Power Cable - Wire Gauge mm² (AWG)
Servo Drive and Servo Motor
L1, L2 R, S, T U, V, W P, C
ECMA-F21830îš…S 1.3 (AWG16) 3.3 (AWG12) 3.3 (AWG12) 3.3 (AWG12)
ECMA-E21835îš…S 1.3 (AWG16) 3.3 (AWG12) 3.3 (AWG12) 3.3 (AWG12)
ASD-A4523-B
ECMA-F21845îš…S 1.3 (AWG16) 3.3 (AWG12) 8.4 (AWG8) 3.3 (AWG12)
ASD-A5523-B ECMA-F21855îš…3 1.3 (AWG16) 3.3 (AWG12) 13.3 (AWG6) 3.3 (AWG12)
ASD-A7523-B ECMA-F21875îš…3 1.3 (AWG16) 5.3 (AWG10) 13.3 (AWG6) 3.3 (AWG12)
Encoder Cable
Encoder Cable - Wire Gauge mm
2
(AWG)
Servo Drive
Wire Size Core Number UL Rating Wire Length
ASD-A4523-B 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84ft.)
ASD-A5523-B 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84 ft.)
ASD-A7523-B 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84 ft.)
NOTE
1) Please use shielded twisted-pair cables for wiring to prevent voltage coupling and eliminate
electrical noise and interference.
2) The shield of shielded twisted-pair cables should be connected to the SHIELD end (terminal
marked
) of the servo drive.
3) In order to prevent fire hazard and accidents, please form the wiring by following the cable
specifications outlined above.
