Chapter 8 Servo Parameters
8-36 Revision January 2011
Settings:
This parameter is used to provide the value of one of the status monitoring functions
found in P0-02. The value of P0-10 is determined by P0-18 (desired drive status)
through communication setting or the keypad. The drive status can be read from the
communication address of this parameter via communication port.
When reading the drive status through the keypad, if P0-02 is set to 24, VAR-2 will
quickly show for about two seconds and then the value of P0-10 will display on the
display.
P0 - 11★ CM3 Status Monitor 3 Address: 0016H, 0017H
Default: N/A Related Section:
Applicable Control Mode: ALL Section 4.3.5
Unit: N/A
Range: N/A
Data Size: 32-bit
Display Format: Decimal
Settings:
This parameter is used to provide the value of one of the status monitoring functions
found in P0-02. The value of P0-11 is determined by P0-19 (desired drive status)
through communication setting or the keypad. The drive status can be read from the
communication address of this parameter via communication port.
When reading the drive status through the keypad, if P0-02 is set to 25, VAR-3 will
quickly show for about two seconds and then the value of P0-11 will display on the
display.
P0 - 12★ CM4 Status Monitor 4 Address: 0018H, 0019H
Default: N/A Related Section:
Applicable Control Mode: ALL Section 4.3.5
Unit: N/A
Range: N/A
Data Size: 32-bit
Display Format: Decimal
Settings:
This parameter is used to provide the value of one of the status monitoring functions
found in P0-02. The value of P0-12 is determined by P0-20 (desired drive status)
through communication setting or the keypad. The drive status can be read from the
communication address of this parameter via communication port.
When reading the drive status through the keypad, if P0-02 is set to 26, VAR-4 will
quickly show for about two seconds and then the value of P0-12 will display on the
display.
