Delta Electronics ASDA-A2 Series - Page 298

Chapter 8 Servo Parameters
Revision January 2011 8-53
P1 - 04 MON1 Analog Monitor Output Proportion 1 (CH1) Address: 0108H, 0109H
Default: 100 Related Section:
Applicable Control Mode: ALL Section 6.4.4
Unit: % (full scale)
Range: 0 ~ 100
Data Size: 16-bit
Display Format: Decimal
P1 - 05 MON2 Analog Monitor Output Proportion 2 (CH2) Address: 010AH, 010BH
Default: 100 Related Section:
Applicable Control Mode: ALL Section 6.4.4
Unit: % (full scale)
Range: 0 ~ 100
Data Size: 16-bit
Display Format: Decimal
P1 - 06 SFLT
Accel / Decel Smooth Constant of Analog
Speed Command (Low-pass Filter)
Address: 010CH, 010DH
Default: 0 Related Section:
Applicable Control Mode: S Section 6.3.3
Unit: msec
Range: 0 ~ 1000 (0: Disabled)
Data Size: 16-bit
Display Format: Decimal
P1 - 07 TFLT
Smooth Constant of Analog Torque
Command (Low-pass Filter)
Address: 010EH, 010FH
Default: 0 Related Section:
Applicable Control Mode: T Section 6.4.3
Unit: msec
Range: 0 ~ 1000 (0: Disabled)
Data Size: 16-bit
Display Format: Decimal
