Delta Electronics ASDA-A2 Series User Manual

Chapter 3 Connections and Wiring
Revision January 2011 3-9
3.1.6 Cable Specifications for Servo Drive
Power Cable
Power Cable - Wire Gauge AWG (mm
2
)
Servo Drive and Servo Motor
L1C, L2C R, S, T U, V, W P , C
ASD-A2-0121- ECMA-C10401S
1.3 (AWG16)
2.1 (AWG14) 0.82 (AWG18) 2.1 (AWG14)
ASD-A2-0221- ECMA-C10602S
1.3 (AWG16)
2.1 (AWG14) 0.82 (AWG18) 2.1 (AWG14)
ECMA-C10604S
1.3 (AWG16)
2.1 (AWG14) 0.82 (AWG18) 2.1 (AWG14)
ECMA-C108047
1.3 (AWG16)
2.1 (AWG14) 0.82 (AWG18) 2.1 (AWG14)
ECMA-E11305S
1.3 (AWG16)
2.1 (AWG14) 0.82 (AWG18) 2.1 (AWG14)
ASD-A2-0421-
ECMA-G11303S
1.3 (AWG16)
2.1 (AWG14) 0.82 (AWG18) 2.1 (AWG14)
ECMA-C10807S
1.3 (AWG16)
2.1 (AWG14) 0.82 (AWG18) 2.1 (AWG14)
ASD-A2-0721-
ECMA-G11306S
1.3 (AWG16)
2.1 (AWG14) 0.82 (AWG18) 2.1 (AWG14)
ECMA-C11010S
1.3 (AWG16)
2.1 (AWG14) 1.3 (AWG16) 2.1 (AWG14)
ECMA-E11310S
1.3 (AWG16)
2.1 (AWG14) 1.3 (AWG16) 2.1 (AWG14)
ASD-A2-1021-
ECMA-G11309S
1.3 (AWG16)
2.1 (AWG14) 1.3 (AWG16) 2.1 (AWG14)
ASD-A2-1521- ECMA-E11315S
1.3 (AWG16)
2.1 (AWG14) 1.3 (AWG16) 2.1 (AWG14)
ECMA-C11020S
1.3 (AWG16)
2.1 (AWG14) 2.1 (AWG14) 2.1 (AWG14)
ECMA-E11320S
1.3 (AWG16)
2.1 (AWG14) 2.1 (AWG14) 2.1 (AWG14)
ASD-A2-2023-
ECMA-E11820S
1.3 (AWG16)
2.1 (AWG14) 3.3 (AWG12) 2.1 (AWG14)
ECMA-E11830S
1.3 (AWG16)
2.1 (AWG14) 3.3 (AWG12) 2.1 (AWG14)
ASD-A2-3023-
ECMA-F11830S
1.3 (AWG16)
2.1 (AWG14) 3.3 (AWG12) 2.1 (AWG14)
ASD-A2-4523- ECMA-F11845S 1.3 (AWG16) 3.3 (AWG12) 8.4 (AWG8) 3.3 (AWG12)
ASD-A2-5523- ECMA-F118553 1.3 (AWG16)
3.3 (AWG12) 13.3 (AWG6)
3.3 (AWG12)
ASD-A2-7523- ECMA-F118753
1.3 (AWG16)
5.3 (AWG10) 13.3 (AWG6) 3.3 (AWG12)
Call 1(800)985-6929 for Sales
deltaacdrives.com
sales@deltaacdrives.com
Call 1(800)985-6929 for Sales
deltaacdrives.com
sales@deltaacdrives.com

Delta Electronics ASDA-A2 Series Specifications

General

Series	ASDA-A2
Category	Controller
Protection Class	IP20
Weight	Varies by model
Control Mode	Position, Speed, Torque
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Output Power	0.1kW to 15kW
Communication Interface	RS-485, CANopen
Type	AC Servo Drive
Encoder Feedback	Incremental, Absolute
Protection Features	Overvoltage, Overcurrent, Overtemperature
