Delta Electronics ASDA-A2 Series - Page 79

Chapter 3 Connections and Wiring
3-38 Revision January 2011
Signal
DO
Code
Function PT PR S T Sz Tz PT-S PT-T PR-S PR-T S-T
SDO_1 0x31
Output the status of
bit01 of P4-06.
SDO_2 0x32
Output the status of
bit02 of P4-06.
SDO_3 0x33
Output the status of
bit03 of P4-06.
SDO_4 0x34
Output the status of
bit04 of P4-06.
SDO_5 0x35
Output the status of
bit05 of P4-06.
SDO_6 0x36
Output the status of
bit06 of P4-06.
SDO_7 0x37
Output the status of
bit07 of P4-06.
SDO_8 0x38
Output the status of
bit08 of P4-06.
SDO_9 0x39
Output the status of
bit09 of P4-06.
SDO_A 0x3A
Output the status of
bit10 of P4-06.
SDO_B 0x3B
Output the status of
bit11 of P4-06.
SDO_C 0x3C
Output the status of
bit12 of P4-06.
SDO_D 0x3D
Output the status of
bit13 of P4-06.
SDO_E 0x3E
Output the status of
bit14 of P4-06.
SDO_F 0x3F
Output the status of
bit15 of P4-06.
NOTE
1) For Pin numbers of DO1~DO5 signals, please refer to section 3.3.1.
