Delta Electronics ASDA-A2 Series - Page 89

Chapter 3 Connections and Wiring
3-48 Revision January 2011
CN2 Terminal Signal Identification
Drive Connector Motor Connector
PIN No.
Terminal
Identification
Description
Military
Connector
Quick
Connector
Color
5 T+
Serial communication
signal input / output (+)
A 1 Blue
4 T-
Serial communication
signal input / output (-)
B 4 Blue/Black
- - Reserved - - -
- - Reserved - - -
14,16 +5V +5V power supply S 7
Red &
Red/White
13,15 GND Ground R 8
Black &
Black/White
- - Shielding L 9 -
