Delta Electronics DVP-ES2 Series - Electrical Specifications

- 2 -
 Electrical Specifications
Model
Item
16ES200 24ES200 32ES200 40ES200 60ES200 20EX200
Power supply
voltage
100 ~ 240VAC (-15% ~ 10%)
, 50/60Hz r 5%
Connector European standard removable terminal block (Pin pitch: 5mm)
Operation
DVP-ES2 starts to run when the power rises to 95 ~ 100VAC and stops
when the power drops to 70VAC. If the power is suddenly cut off, the MPU
will continue running for 10ms.
Power supply
fuse
2A/250VAC
Power
consumption
30VA 30VA 30VA 30VA 30VA 30VA
DC24V current
output
500mA 500mA 500mA 500mA 500mA 500mA
Power supply
protection
DC24V output short circuit protection
Voltage
withstand
1,500VAC (Primary-secondary)
, 1,500VAC (Primary-PE),
500VAC (Secondary-PE)
Insulation
resistance
> 5Mȍ at 500VDC (between all I/O points and ground)
Noise immunity
ESD: 8KV Air Discharge
EFT: Power Line: 2KV, Digital I/O: 1KV, Analog & Communication I/O: 1KV
RS: 26MHz ~ 1GHz, 10V/m
Grounding
The diameter of grounding wire shall not be less than that of L, N terminal of
the power supply. (When many PLCs are in use at the same time, please
make sure every PLC is properly grounded.)
Environment
Operation: 0°C~55°C (temperature), 50~95% (humidity), pollution degree 2
Storage: -25°C~70°C (temperature), 5~95% (humidity)
Vibration/shock
resistance
International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/ IEC61131-2 &
IEC 68-2-27 (TEST Ea)
Weight
R: 377g
T: 351g
R: 414g
T: 387g
R: 489g
T: 432g
R: 554g
T: 498g
R: 696g
T: 614g
R: 462g
T: 442g
Input Point
Input point type Digital input
Input type DC (SINK or SOURCE)
Input current 24VDC, 5mA
Input No. X0, X2 X1, X3 ~ X7
X10 ~ X17, X20 ~
#1
Off ĺ On >15VDC
Action level
On ĺ Off < 5VDC
Off ĺ On 2.5ȝs 20ȝs 10ms
Response time
On ĺ Off 5ȝs 50ȝs 10ms
Filter time X0 ~ X7 Adjustable within 0 ~ 20ms in D1020 (Default: 10ms)
Input impedance 4.7Kȍ
Output Point
Output point type Relay-R Transistor-T
Output point number All Y0, Y2 Y1, Y3
Y4~Y17, Y20~
#1
Voltage specification < 250VAC, 30VDC
5 ~ 30VDC
#2
Maximum load
Resistive 2A/1 point (5A/COM) 0.5A/1 point (4A/COM)
