Chapter 2 Introduction
3
Chapter 2 : Introduction
2.1 General Overview
The STS is designed to guarantee the uninterrupted operation of sensitive equip-
ment. It is powered by two independent power sources and automatically makes a
rapid switch from one source to the other when the original power supplying to its
connected load fails.
The user can know the power ow and STS’s status from the front panel’s LED indi-
cators and monitor the STS via the built-in InsightPower SNMP IPv6 card. The unit
has a network interface for the user to read and write parameters and the network
interface can be implemented via the Ethernet protocol through an RJ45 connector.
The STS is designed to be efcient and reliable.
2.2 Package List
1 1
1
2 3 4 5
STS30002SR00035 STS30002SR10035
STS30002SR10135
TEST
O/P
S1
S1-ON
S2
S2-ON
NETWORK
RESET
LOCAL
TEST
O/P
S1 S1-ON
S2 S2-ON
NETWORK
RESET
LOCAL
TEST
O/P
S1 S1-ON
S2
S2-ON
RESET
NETWORK
LOCAL
