Set ting up Mas ter / Slave op er a tion:
• Connect the out put ter mi nals and test the sys tem in nor mal par al lel or se ries op er a tion. En sure that all (out put)
power con nec tions are re li able. An in ter rup tion of one of the power leads can cause a PTC fuse in side the unit to
trip.
• The volt age drop across the power leads be tween the units should be kept < 10 mV.
• Switch off all units. For Mas ter / Slave se ries op er a tion, use a Mas ter / Slave Se ries Adapter for each slave.
Plug in the pro gram ming con nec tors with the con nec tions ac cord ing to one of the fig ures be low. Put both
pro gram ming switches on the slave power sup plies in the "PROG" po si tion and switch the units on again.
• The to tal out put volt age and cur rent can now be con trolled by the knobs on the mas ter.
• Al ways use shielded ca bles for the pro gram ming con nec tors and the M/S Se ries Adapt ers.
The shield ing should be con nected to pin 1 of the pro gram ming con nec tor, only at one end.
• The max i mum num ber of slaves in se ries op er a tion is lim ited by the max i mum to tal volt age of 600 V.
• A com bi na tion of Mas ter / Slave par al lel and se ries is also al lowed.
For each se ries slave, a Mas ter / Slave Se ries Adapter must be used.
DELTA ELEKTRONIKA BV ES030-10
Page 3 - 4 DESCRIPTIONS Rev. Sept. 2012
Mas ter / Slave se ries op er a tion
Mas ter / Slave par al lel op er a tion
