2 3
PACKAGE CONTENTS
A
1
B
3
C
5
2
4
PART DESCRIPTION QTY
1
Fan Body 1
2
Grille 1
3
Suspension bracket
Ⅰ
13”(318.5mm) 2
4
Suspension bracket
Ⅱ
13”(318.5mm) 2
5
Duct Connector 1
HARDWARE CONTENTS
(Images are to scale)
× 4
Long Wood Screw ( ø 4 x 25mm)
× 4
Short screw (#8-32x1/4”)
× 1
Duct Screw (M4x12mm)
