CARE AND MAINTENANCE
See safety information before proceeding. Routine maintenance should be done at least once a year.
• Never use solvents, thinner or harsh chemicals when cleaning the fan.
• Do not allow water to enter the motor.
• Do not immerse metal parts in water.
• Do not immerse resin parts in water over 140º Fahrenheit.
Turn o power source. Review all safety precautions.
1. To remove grille
2
, squeeze springs and pull down.
2. Wash and clean the grille
2
in a sink and dry with a cloth.
3. Remove dust and dirt from the fan body
1
with
a vacuum cleaner.
4. Dampen cloth with dust detergent and wipe the fan body
1
. Then wipe dry with a clean cloth.
5. Replace grille
2
back onto fan body
1
.
6. Turn on power source to operate fan again.
3
4
5
1
2
