Delta COMMIX User Manual

24
3
2
2
32
1
Loosen and remove the inner fixed panel support (F).
This will be the assembly closest to the exposed glass
edge (shown in figure 32).
This will allow the top track to be carefully lowered for
the next few steps.
Afloje u retire el apoyo del panel fijo interno (F). Este
será el ensamble más cercano al borde de vidrio
expuesto (mostrado en la figura 32).
Esto permitirá que el carril superior sea bajado
cuidadosamente para realizar los siguientes pasos.
Make sure that outline traced in step 30 aligns with the
top track (C).
Confirme que el trazo descrito en el paso 30 queda
alineado con el carril superior (C).
31
C
