Product Specifications
Power Requirements
24 VAC, Class 2, 60Hz
Power Consumption
12 VA
48 VA max (with fully loaded Binary Outputs (Triacs))
Ambient Ratings
32° to 131°F (0° to 55°C), 10 to 90% RH (non condensing)
Communication Ports
NET1
 BACnet MS/TP (RS-485)
 Communication: 9600, 19200, 38400, 76800 bps (Default)
 Maximum of 99 controllers
NET2
 LINKnet
 Communication: 76800 bps
 Maximum of 6 LINKnet controllers including up to two DFM
controllers
Service
Port
 RJ-11 Jack
 Used with Delta Controls service tool devices (for example,
CON-768)
Inputs
6 Universal Inputs (10 bit), jumper configurable for the following input
types:
 0-5 VDC
 0-10 VDC
 10 KΩ Thermistor
 Dry Contact (using 10 KΩ Thermistor jumper setting
 4-20 mA
Outputs
3 Analog Outputs c/w LED status indication
 0-10 VDC @ 20mA maximum per output
 Software configurable as binary or analog
3 Binary Triac Outputs c/w LED status indication
 Switching 24VAC@0.5 Amp maximum per output
 Leakage Current per Triac is 160 µA
Technology
32 bit processor
1 MB (8 megabit) Flash Memory
256 KB SRAM memory
Listings
UL 916 Listed
BTL Listed
UL 864 Listed (DAC-633-UL864 model only)
Compliance
CE
FCC
