Delta DOP-B - DOP-B07 S(E)515; DOP-B07 PS515 Cut-out; DOP-B08 S(E)515 Cut-out

English-16
DOP-B07S(E)515 ／ DOP-B07PS515
184(7.24")
144 (5.67")
+1.0
172.4
0
T
+1.0
132.4
0
(5.21" )
Note:
T=1.6mm(0.063")~
6mm(0.24")
+0.04"
(6.79" )
0
+0.004"
0
43(1.69")
131(5.16")
DOP-B08S(E)515
T=1.6mm(0.06") ~
5.0mm(0.19")
(2.06")
174.1(6.85")
227.1(8.94")
0
+0.04"
(8.63" )
0
219.4
+1
+0.04"
6.55"
0
+1
166.5
0
NOTE:
4-R1.0(0.04")
52.3
T
Units: mm (inches)
Units: mm (inches)
