Delta DOP-B - Ethernet Interface (LAN)

English-6
Ethernet Interface (LAN)
Ethernet Interface (LAN) PIN
Contact
Ethernet
1
TX+
2
TX-
3
RX+
4
5
6
RX-
7
8
Note: Blank = No Connection.
DOP-B05 / DOP-B07S(E)515 / DOP-B07PS515 Series
COM1 Port (Supports Flow Control)
COM Port PIN
Contact
RS-232
1
2
RXD
3
TXD
4
5
GND
6
7
RTS
8
CTS
9
Note: Blank = No Connection.
COM2 and COM3 Port
COM Port PIN
MODE1
MODE2
MODE3
COM2
COM3
COM2
COM3
COM2
COM3
RS-232
RS-485
RS-485
RS-485
RS-232
RS-422
1
D+
TXD+
2
RXD
RXD
3
TXD
TXD
4
D+
D+
RXD+
5
GND
GND
GND
6
D-
TXD-
7
8
9
D-
D-
RXD-
Note1: Blank = No Connection.
Note2: B05 / B07S(E)515/ B07PS515 series models do not support RS-422 flow control function.
PIN1
PIN1
