Multi-functional Power Meter DPM-C510 Operation Manual
5-8
After receiving response from the power meter, Modbus Master acquires the value of currents from the
primary-side current transformer (register address 0x000E), which is 1000.
Should Modbus Slave (power meter) receive an abnormal Request, the format of the abnormal packet
responded is as follows.
Slave Response
0x01 0x83 0x1
Slave
Address
Function
Code
Exception
Code
CRC
