A.3 DCT1000 Series
Electromagnetic Compatibility: CE-marking, IEC61869-2.
Model
Number
Measurement
Accuracy
Primary
Current
Secondary
Current
Rated
Burden
(VA)
External
Dimension*1
(mm)
Size of
Opening*1
(mm)
DCT-S301C 1.0% 100 A 5 A 1.5
90 x 40 x 111 21 x 32
DCT-S211C 0.5% 200 A 5 A 1
DCT-S221C 0.5% 300 A 5 A 1.5
DCT-S231C 0.5% 400 A 5 A 2.5
DCT-S241C 0.5% 500 A 5 A 2.5
116.5 x 52 x 147 50 x 80
DCT-S251C 0.5% 600 A 5 A 2.5
DCT-S261C 0.5% 750 A 5 A 2.5
DCT-S271C 0.5% 1000 A 5 A 5
DCT-S281C 0.5% 1500 A 5 A 7.5
146.5 x 51.6 x
198
80 x 122
DCT-S291C 0.5% 2000 A 5 A 10
186.5 x 52 x 252 81 x 160.5 DCT-S2A1C 0.5% 2500 A 5 A 15
DCT-S2B1C 0.5% 3000 A 5 A 20
*1: See the following table for detailed information on the external dimensions and sizes of opening.
