Delta DPM-C530A - Page 34

33
16A
Positive active electric energy on
three phases - Opposite active
electric energy on three phases
0x80000001 ~ 0x7FFFFFFF
(negative for 2’s complement)
int Wh 4 R
16B
16C
Positive reactive electric energy
on three phases + Opposite
reactive electric energy on three
phases
0x00000000~0xFFFFFFFF Uint VARh 4 R
16D
16E
Positive reactive electric energy
on three phases - Opposite
reactive electric energy on three
phases
0x80000001 ~ 0x7FFFFFFF
(negative for 2’s complement)
int VARh 4 R
16F
170
Positive apparent electric energy
on three phases + Opposite
apparent electric energy on three
phases
0x00000000~0xFFFFFFFF Uint VAh 4 R
171
172
Positive apparent electric energy
on three phases - Opposite
apparent electric energy on three
phases
0x80000001 ~ 0x7FFFFFFF
(negative for 2’s complement)
int VAh 4 R
173
174
Total harmonic distortion for
current on phase A
0.000~999.999 Float % 4 R
175
176
Total harmonic distortion for
current on phase B
0.000~999.999 Float % 4 R
177
178
Total harmonic distortion for
current on phase C
0.000~999.999 Float % 4 R
179
17A
Total harmonic distortion on
neutral current
0.000~999.999 Float % 4 R
17B
17C
Total harmonic distortion for
voltage on phase A
0.000~999.999 Float % 4 R
17D
17E
Total harmonic distortion for
voltage on phase B
0.000~999.999 Float % 4 R
17F
180
Total harmonic distortion for
voltage on phase C
0.000~999.999 Float % 4 R
181
182
Total harmonic distortion for
voltage on line AB
0.000~999.999 Float % 4 R
183
184
Total harmonic distortion for
voltage on line BC
0.000~999.999 Float % 4 R
185
186
Total harmonic distortion for
voltage on line CA
0.000~999.999 Float % 4 R
187
188
Total harmonic distortion for
current
0.000~999.999 Float % 4 R
189
18A
Total harmonic distortion for
voltage
0.000~999.999 Float % 4 R
18B
