58
0707
Phase C voltage with 11 harmonic
component 0.000~999.999
Float % 4 R
…
0.000~999.999
Float % 4 R
0708
Phase C voltage with 21 harmonic
component 0.000~999.999
Float % 4 R
…
0.000~999.999
Float % 4 R
Phase C voltage with 31 harmonic
component 0.000~999.999
Float % 4 R
0709
Phase A current with 1 harmonic
component 0.000~999.999
Float % 4 R
…
0.000~999.999
Float % 4 R
070A
Phase A current with 11 harmonic
component 0.000~999.999
Float % 4 R
…
0.000~999.999
Float % 4 R
070B
Phase A current with 21 harmonic
component 0.000~999.999
Float % 4 R
…
0.000~999.999
Float % 4 R
Phase A current with 31 harmonic
component 0.000~999.999
Float % 4 R
070C
Phase B current with 1 harmonic
component 0.000~999.999
Float % 4 R
…
0.000~999.999
Float % 4 R
070D
Phase B current with 11 harmonic
component 0.000~999.999
Float % 4 R
…
0.000~999.999
Float % 4 R
070E
Phase B current with 21 harmonic
component 0.000~999.999
Float %
4 R
…
0.000~999.999
Float % 4 R
Phase B current with 31 harmonic
component 0.000~999.999
Float % 4 R
070F
Phase C current with 1 harmonic
component 0.000~999.999
Float % 4 R
…
0.000~999.999
Float % 4 R
0710
Phase C current with 11 harmonic
component 0.000~999.999
Float % 4 R
…
0.000~999.999
Float % 4 R
0711
Phase C current with 21 harmonic
component 0.000~999.999
Float % 4 R
…
0.000~999.999
Float % 4 R
Phase C current with 31 harmonic
component 0.000~999.999
Float % 4 R
the Data of a day: 0800 ~
Interval: 1 min
Data recording priority for each register
year, month, date byte 3
Hour, minute, second byte 3
Phase voltage Float 4
Line voltage Float 4
