1016H Temperature regulation value -999~+999, unit: 0.1
1017H Analog decimal setting 0 ~ 3
1018H Time for valve from full open
to full close
0.1~999.9
1019H Dead Band setting of valve 0~100%; unit: 0.1%
101AH Upper-limit of feedback
signal set by valve
0~1024
101BH Lower-limit of feedback
signal set by valve
0~1024
101CH PID parameter selection 0~4
101DH SV value corresponded to
PID value
Only valid within available range, unit: 0.1 scale
1020H Alarm 1 type Please refer to the contents of the “Alarm Outputs” for detail
1021H Alarm 2 type Please refer to the contents of the “Alarm Outputs” for detail
1022H Alarm 3 type Please refer to the contents of the “Alarm Outputs” for detail
1023H System alarm setting 0 : None (default), 1~3 : Set Alarm 1 to Alarm 3
1024H Upper-limit alarm 1 Please refer to the contents of the “Alarm Outputs” for detail
1025H Lower-limit alarm 1 Please refer to the contents of the “Alarm Outputs” for detail
1026H Upper-limit alarm 2 Please refer to the contents of the “Alarm Outputs” for detail
1027H Lower-limit alarm 2 Please refer to the contents of the “Alarm Outputs” for detail
1028H Upper-limit alarm 3 Please refer to the contents of the “Alarm Outputs” for detail
1029H Lower-limit alarm 3 Please refer to the contents of the “Alarm Outputs” for detail
102AH
Read LED status
b0 : Alm3, b1: Alm2, b2: F, b3: ℃, b4: Alm1, b5: OUT2, b6: OUT1, b7: AT
102BH Read pushbutton status b0 : Set, b1 : Select, b2 : Up, b3 : Down. 0 is to push
102CH Setting lock status 0 : Normal, 1 : All setting lock, 11 : Lock others than SV value
102DH CT read value Unit: 0.1A
102FH Software version V1.00 indicates 0x100
1030H Start pattern number 0 ~ 7
1040H~
1047H
Actual step number setting
inside the correspond pattern
0 ~ 7 = N, indicate that this pattern is executed from step 0 to step N
1050H~
1057H
Cycle number for repeating
the execution of the
correspond pattern
0 ~ 99 indicate that this pattern has been executed for 1 ~ 100 times
1060H~
1067H
Link pattern number setting of
the correspond pattern
0 ~ 8, 8 indicates the program end. 0~7 indicates the next execution pattern
number after executing the current pattern
2000H~
203FH
Pattern 0~7 temperature set
point setting
Pattern 0 temperature is set to
2000H~2007H
-999 ~ 9999
2080H~
20BFH
Pattern 0~7 execution time
setting
Pattern 0 time is set to
2080H~2087H
Time 0 ~ 900 (1 minute per scale)
6. Address and Content of Bit Register: ( First bit of reading will put into LSB, Write data = FF00H for bit set,
0000H for bit clear)
0810H
Communication write-in
selection
Communication write in disabled: 0 (default), Communication write in
enabled: 1
0811H
Temperature unit display
selection
o
C / linear input (default) : 1 ,
o
F : 0
0812H
Decimal point position
selection
Except for the thermocouple B, S, R type, all the other thermocouple type
are valid. (0 or 1)
0813H AT setting OFF: 0 (default), ON : 1
0814H Control RUN/STOP setting 0 : STOP, 1 : RUN (default)
0815H
STOP setting for PID
program control
0: RUN (default), 1: STOP
