DVP-ES2/EX2/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-90
API Mnemonic Operands Function
Controllers
ES2/EX2/
EC5
SS2
SA2
SE
SX2
29 D NEG P
2’s Complement
(Negation)
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
NEG, NEGP: 3 steps
DNEG, DNEGP: 5 steps
D * * * * * * * *
PULSE
16-bit
32-bit
ES2/EX2
/EC5
SS2
SA2
SE
SX2
ES2/EX2
/EC5
SS2
SA2
SE
SX2
ES2/EX2
/EC5
SS2
SA2
SE
SX2
Operands:
D: Device to store the operation result of 2’s Compliment
Explanations:
1. This instruction conducts operation of 2’s complement and can be used for converting a
negative BIN value into an absolute value.
2. This instruction is generally used in pulse execution mode (NEGP, DNEGP).
3. If operand D uses index F, only a 16-bit instruction is available.
Program Example 1:
When X0 goes from OFF to ON, the phase of each bit in D10 will be reversed (0→1, 1→0) and then
1 will be added to the Least Significant Bit (LSB) of the register. Operation result will then be stored
in D10.
X0
NEGP
D10
Program Example 2:
To obtain the absolute value of a negative value:
1. When MSB (b15) of D0 is “1”, M0 = ON. (D0 is a negative value).
2. When M0 = ON, the absolute value of D0 can be obtained by NEG instruction.
M1000
BON D0 K15M0
M0
NEGP D0
Program Example 3:
Obtain the absolute value of the remainder of the subtraction. When X0 = ON,
a) If D0 > D2, M0 = ON.
b) If D0 = D2, M1 = ON.
c) If D0 < D2, M2 = ON.
