3. Instruction Set
Points to note:
1. Operand S must be a multiple of 10, e.g. 00, 10, 20, which means X0, X10… etc. and
occupies 8 continuous devices.
2. Operand D
1
should be a multiple of 10, i.e. 00, 10, 20, which means Y0, Y10… etc. and
occupies n continuous devices
3. Operand D
2
should be a multiple of 10, i.e. 00, 10, which means M0, M10, S0, S10… etc.
4. Valid range of n = 2~8
