DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3
-226
The following table shows the state of the output point Y when the high-speed counter C251
reaching 6800.
Output point Y number Y0 Y1 Y2
16-bit value ON OFF OFF
Device D number D2000 D2001 D2002
Value of the head index (16-bit) K4 K4 K4
Device D number D2003 D2004 D2005
Value of the tail index (16-bit) K4 K3 K1
The following table shows the state of the output point Y when the high-speed counter C251
reaching 7300.
Output point Y number Y0 Y1 Y2
16-bit value OFF OFF ON
Device D number D2000 D2001 D2002
Value of the head index (16-bit)
K4 K4 K4
Device D number
D2003 D
2004 D2005
Value of the tail index (16-bit)
K4 K3 K2
The following table shows the state of the output point Y when the high-speed counter C251
reaching 7700.
Output point Y number Y0 Y1 Y2
16-bit value OFF ON OFF
Device D number D2000 D2001 D2002
Value of the head index (16-bit) K4 K4 K4
Device D number D2003 D2004 D2005
Value of the tail index (16-bit) K4 K4 K3
