DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-408
API Mnemonic Operands Function
Controllers
ES2/EX2/
EC5
SS2
SA2
SE
SX2
112 D MOVR P Move floating point data
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
DMOVR, DMOVRP: 9
steps
S
D
*
*
*
*
*
*
PULSE
16-bit
32-bit
ES2/EX2/
EC5
SS2
SA2
SE
SX2
ES2/EX2/
EC5
SS2
SA2
SE
SX2
ES2/EX2/
EC5
SS2
SA2
SE
SX2
Operands:
S: Source device D: Destination device
Explanations:
1. S can only be a constant floating point value.
2. When the instruction executed, content of S will be moved to D.
3. If users want to move the floating-point value in registers, they have to use DMOV.
Program Example:
When X0 = OFF, D10 and D11 will not change. When X0 = ON, transmit F1.200E+0 (Input F1.2,
and scientific notation F1.200E+0 will be displayed on ladder diagram. Users can set monitoring
data format as float on the function View) to D10 and D11.
X0
DMOVR F1.200E+0
D10
