Delta DVP-ES2 - Page 62

DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
2-26
Special
M
Function
ES2
EX2
EC5
SS2
SA2
SE
SX2
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
M1584
If the left limit switch of CH0 is enabled, it
can be triggered either by a rising-edge
signal or by a falling-edge signal. (OFF:
Rising-edge signal; ON: Falling-edge
signal); available for ES2/EX2: V3.2, EC5:
V1.00 or later
○
V3.0
V2.8
V1.4
V2.6 OFF OFF - R/W NO OFF
M1585
If the left limit switch of CH1 is enabled, it
can be triggered either by a rising-edge
signal or by a falling-edge signal. (OFF:
Rising-edge signal; ON: Falling-edge
signal); available for ES2/EX2: V3.2,
EC5: V1.00 or later
○
V3.0
V2.8
V1.4
V2.6 OFF OFF - R/W NO OFF
M1586
If the left limit switch of CH2 is enabled, it
can be triggered either by a rising-edge
signal or by a falling-edge signal. (OFF:
Rising-edge signal; ON: Falling-edge
signal);
EC5
╳ ╳ ╳
OFF OFF - R/W NO OFF
M1587
If the left limit switch of CH3 is enabled, it
can be triggered either by a rising-edge
signal or by a falling-edge signal. (OFF:
Rising-edge signal; ON: Falling-edge
signal);
EC5
╳ ╳ ╳
OFF OFF - R/W NO OFF
M1588
When M1588=ON, set the zero point for
the first DZRN auto-reset (Y4, Y6) to the
position wher DOG point stops on the
positive direction. (If M1588 is OFF, it
stops on the negative direction.)
EC5
╳ ╳ ╳
OFF OFF - R/W NO OFF
M1589
When M1589=ON, set the zero point for
the first DZRN auto-reset (Y4, Y6) to the
position wher DOG point stops on the
positive direction. (If M1589 is OFF, it
stops on the negative direction.)
EC5
╳ ╳ ╳
OFF OFF - R/W NO OFF
M1590
Enabling the acceleration of the Ethernet
data exchange (ON: Enable; OFF:
Disable)
╳ ╳
V2.66
V1.4
V2.66
OFF OFF - R/W NO OFF
M1598*
Enabling the fetching of the value in the
hardware counter
C243/C245/C246/C247/C248/C251/C252
, and using X6 as a fetching signal (ON:
Enable; OFF: Disable)
ES2/
EX2:
V3.28
V
3.28
SA2:
V2.82
V2.82
OFF - - R/W NO OFF
M1599*
Enabling the fetching of the value in the
hardware counter
C244/C249/C250/C253/C254, and using
X7 as a fetching signal (ON: Enable;
OFF: Disable)
ES2/
EX2:
V3.28
V
3.28
SA2:
V2.82
V2.82
OFF - - R/W NO OFF
M1604
Enable pulse output at the maximum
frequency of the ramp up/down set in
D1410 and D1411 for the fixed slope of
Y0 or CH0 (Y0/Y1). (ON: Enable; OFF:
Disable) Available for ES2/EX2: V3.28,
ES2-E: V1.00, EC5: V1.00, 12SA2/SX2:
V2.82, SS2: V3.24, SE: V2.00, 28SA2:
V2.90.
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1605
Enable pulse output at the maximum
frequency of the ramp up/down set in
D1412 and D1413 for the fixed slope of
Y2 or CH1 (Y2/Y3). (ON: Enable; OFF:
Disable) Available for ES2/EX2: V3.28,
ES2-E: V1.00, EC5: V1.00, 12SA2/SX2:
V2.82, SS2: V3.24, SE: V2.00, 28SA2:
V2.90.
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1606
Enable pulse output at the maximum
frequency of the ramp up/down set in
D1988 and D1989 for the fixed slope of
Y1. (ON: Enable; OFF: Disable) Available
for ES2/EX2: V3.28, ES2-E: V1.00,
12SA2/SX2: V2.82, SS2: V3.24, SE:
V2.00, 28SA2: V2.90.
ES2/
EX2
╳ ○ ○
OFF OFF - R/W NO OFF
M1607
Enable pulse output at the maximum
frequency of the ramp up/down set in
ES2/
EX2
╳ ○ ○
OFF OFF - R/W NO OFF
