DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-568
API Mnemonic Operands Function
Controllers
ES2/EX2
SS2
SA2
SE
SX2
269 D BLD Load NO Contact by Specified Bit
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
BLD: 5 steps
DBLD: 9 steps
S
*
*
*
*
*
*
n
*
*
*
*
*
*
*
*
*
*
*
PULSE
16-bit
32-bit
ES2/
EX2
SS2
SA2/
SE
SX2
ES2/
EX2
SS2
SA2/
SE
SX2
ES2/
EX2
SS2
SA2/
SE
SX2
Operands:
S: Reference source device n: Reference bit
Explanations:
1. For ES2/EX2 models, only V1.20 or above supports the function.
2. Available range for the value in operand n: K0~K15 for 16-bit instruction; K0~K31 for 32-bit
instruction.
BLD instruction is used to load NO contact whose contact state is defined by the reference bit n in
reference device D, i.e. if the bit specified by n is ON, the NO contact will be ON, and vice versa.
Program Example:
BLD D0 K3
Y0
Instruction: Operation:
BLD
D0 K3
Load NO contact with bit
status of bit3 in D0
OUT Y0 Drive coil Y0
