DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-678
11. Explanation of DOG (A) and DOG (B) signals
Contact
Type
DOG
(A)
The DOG signal emerges and the axis
enters DOG when the contact switches from
OFF to ON.
The DOG signal disappears and the axis
leaves DOG when the contact switches from
ON to OFF.
DOG
(B)
The DOG signal emerges and the axis
enters DOG when the contact switches from
ON to OFF.
The DOG signal disappears and the axis
leaves DOG when the contact switches from
OFF to ON.
12. Explanation of homing modes
Mode 0：Directly clear the current position to 0.
