Delta DVP-ES2 User Manual

2. Programming Concepts
2-47
Special
D
Content
ES2
EX2
EC5
SS2
SA2
SE
SX2
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
connection ID#14
D1464*
Data length to be written for PLC LINK
connection ID#15
○ ○ ○ ○
- - - R/W YES 16
D1465*
Data length to be written for PLC LINK
connection ID#16
○ ○ ○ ○
- - - R/W YES 16
D1480*
↓
D1495*
The data which is read from connection
ID#1 on PLC LINK at the time when
M1353 is OFF
○ ○ ○ ○
0 - - R NO 0
The initial data register where the data
read from connection ID#1~ID#16 on PLC
LINK is stored at the time when M1353 is
ON
○ ○ ○ ○
- - - R YES 0
D1496*
↓
D1511*
The data which is written into connection
ID#1 on PLC LINK at the time when
M1353 is OFF
○ ○ ○ ○
0 - - R/W NO 0
The initial data register where the data
written into connection ID#1~ID#16 on
PLC LINK is stored at the time when
M1353 is ON
○ ○ ○ ○
- - - R/W YES 0
D1512*
↓
D1527*
The data which is read from connection
ID#2 on PLC LINK
○ ○ ○ ○
0 - - R NO 0
D1528*
↓
D1543*
The data which is written into connection
ID#2 on PLC LINK
○ ○ ○ ○
0 - - R/W NO 0
D1544*
↓
D1559*
The data which is read from connection
ID#3 on PLC LINK
○ ○ ○ ○
0 - - R NO 0
D1560*
↓
D1575*
The data which is written into connection
ID#3 on PLC LINK
○ ○ ○ ○
0 - - R/W NO 0
D1576*
↓
D1591*
The data which is read from connection
ID#4 on PLC LINK
○ ○ ○ ○
0 - - R NO 0
D1592*
↓
D1607*
The data which is written into connection
ID#4 on PLC LINK
○ ○ ○ ○
0 - - R/W NO 0
D1608*
↓
D1623*
The data which is read from connection
ID#5 on PLC LINK
○ ○ ○ ○
0 - - R NO 0
D1624*
↓
D1639*
The data which is written into connection
ID#5 on PLC LINK
○ ○ ○ ○
0 - - R/W NO 0
D1640*
↓
D1655*
The data which is read from connection
ID#6 on PLC LINK
○ ○ ○ ○
0 - - R NO 0
D1656*
↓
D1671*
The data which is written into connection
ID#6 on PLC LINK
○ ○ ○ ○
0 - - R/W NO 0
D1672*
↓
D1687*
The data which is read from connection
ID#7 on PLC LINK
○ ○ ○ ○
0 - - R NO 0
D1688*
↓
D1703*
The data which is written into connection
ID#7 on PLC LINK
○ ○ ○ ○
0 - - R/W NO 0
D1704*
↓
D1719*
The data which is read from connection
ID#8 on PLC LINK
○ ○ ○ ○
0 - - R NO 0
D1720*
↓
D1735*
The data which is written into connection
ID#8 on PLC LINK
○ ○ ○ ○
0 - - R/W NO 0
D1736*
↓
D1751*
The data which is read from connection
ID#9 on PLC LINK
○ ○ ○ ○
0 - - R NO 0
D1752*
↓
D1767*
The data which is written into connection
ID#9 on PLC LINK
○ ○ ○ ○
0 - - R/W NO 0
