Appendix C Inforamation about TP Series Text Panels
C-17
Special
M
Function
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch-
ed
Default
M1075
Error occurring when write in Flash ROM
OFF - - R NO OFF
M1080
COM2 monitor request
OFF - - R/W NO OFF
M1081
Changing conversion mode for FLT instruction
OFF - - R/W NO OFF
M1085
Selecting DVP-PCC01 duplicating function
OFF - - R/W NO OFF
M1086
Enabling password function for DVP-PCC01
OFF - - R/W NO OFF
M1088
Matrix comparison.
Comparing between equivalent values (M1088 = ON) or
different values (M1088 = OFF).
OFF OFF - R/W NO OFF
M1089
Indicating the end of matrix comparison. When the
comparison reaches the last bit, M1089 = ON.
OFF OFF - R NO OFF
M1090
Indicating start of matrix comparison. When the comparison
starts from the first bit, M1090 = ON.
OFF OFF - R NO OFF
M1091
Indicating matrix searching results. When the comparison
has matched results, comparison will stop immediately and
M1091 = ON.
OFF OFF - R NO OFF
M1092
Indicating pointer error. When the pointer Pr exceeds the
comparison range, M1092 = ON
OFF OFF - R NO OFF
M1093
Matrix pointer increasing flag. Adding 1 to the current value
of the Pr.
OFF OFF - R/W NO OFF
M1094
Matrix pointer clear flag. Clear the current value of the Pr to
0
OFF OFF - R/W NO OFF
M1095
Carry flag for matrix rotation/shift/output.
OFF OFF - R NO OFF
M1096
Borrow flag for matrix rotation/shift/input
OFF OFF - R/W NO OFF
M1097
Direction flag for matrix rotation/displacement
OFF OFF - R/W NO OFF
M1098
Counting the number of bits which are “1” or “0”
OFF OFF - R/W NO OFF
M1099
ON when the bits counting result is “0”
OFF OFF - R/W NO OFF
M1120*
Retaining the communication setting of COM2 (RS-485),
modifying D1120 will be invalid when M1120 is set.
OFF OFF - R/W NO OFF
M1121
For COM2(RS-485), data transmission ready
OFF ON - R NO OFF
M1122
For COM2(RS-485), sending request
OFF OFF - R/W NO OFF
M1123
For COM2(RS-485), data receiving completed
OFF OFF - R/W NO OFF
M1124
For COM2(RS-485), data receiving ready
OFF OFF - R/W NO OFF
M1125
For COM2(RS-485), communication ready status reset
OFF OFF OFF R/W NO OFF
M1126
For COM2(RS-485), set STX/ETX as user defined or system
defined
OFF OFF OFF R/W NO OFF
M1127
For COM2(RS-485), data sending/receiving/converting
completed. (RS instruction is not supported)
OFF OFF OFF R/W NO OFF
M1128
For COM2(RS-485), Transmitting/Receiving status Indication
OFF OFF OFF R/W NO OFF
M1129
For COM2(RS-485), receiving time out
OFF OFF - R/W NO OFF
