Appendix E Communication of DVP Series Slim Type Special Modules
E-3
Step 2: Make sure the module is supplied with power and is connected to RS485 before setting.
Click Setup and start to set up the COM port and the baud rate. After the setup is done, click OK to
save the setting.
Step 3: Click Scan to connect to the module and monitor the current values of the control registers
