CR# Address Latched Attribute Register content Description
#8 H’406C X R CH3 average degrees (Unit: 0.1°C).
DVP06PT-S:
Average degrees for CH1 ~ 6
(Unit: 0.1°C).
#9 H’406D X R CH4 average degrees
#10 -- X R CH5 average degrees
#11 -- X R CH6 average degrees
#12 H’4070 X R CH1 average degrees
DVP04PT-S:
Average degrees for CH1 ~ 4
(Unit: 0.1°F).
DVP06PT-S:
Average degrees for CH1 ~ 6
(Unit: 0.1°F).
#13 H’4071 X R CH2 average degrees
#14 H’4072 X R CH3 average degrees
#15 H’4073 X R CH4 average degrees
#16 -- X R CH5 average degrees
#17 -- X R CH6 average degrees
#18 H’4076 X R Present temp. of CH1
DVP04PT-S:
Present temperature of
CH1 ~ 4 (Unit: 0.1°C).
DVP06PT-S:
Present temperature of
channels CH1 ~ 6
(Unit: 0.1°C).
#19 H’4077 X R Present temp. of CH2
#20 H’4078 X R Present temp. of CH3
#21 H’4079 X R Present temp. of CH4
#22 -- X R Present temp. of CH5
#23 -- X R Present temp. of CH6
#24 H’407C X R Present temp. of CH1
DVP04PT-S:
Present temperature of
CH1 ~ 4 (Unit: 0.1°F).
DVP06PT-S:
Present temperature of
channels CH1 ~ 6
(Unit: 0.1°F)..
#25 H’407D X R Present temp. of CH2
#26 H’407E X R Present temp. of CH3
#27 H’407F X R Present temp. of CH4
#28 -- X R Present temp. of CH5
#29 -- X R Present temp. of CH6
#29 H’4081 X R/W
DVP04PT-S:
PID mode setup
Set H’5678 as PID mode and
other values as normal mode
Default value is H’0000.
#30 H’4082 X R Error status
Data register stores the error
status. Refer to the error code
chart for details.
#31
H’4083 O R/W
DVP04PT-S:
Communication address
setup
Set up the RS-485
communication address; setting
range: 01~254. Default: K1
-- X R/W
DVP06PT-S:
CH5~CH6 Mode setting
CH5 mode: b0 ~ b3
CH6 mode: b4 ~ b7
See CR#1 for reference
32
H’4084 O R/W
DVP04PT-S:
Communication baud rate
setting
Communication format: ASCII
mode is 7 bits, even bit, 1 stop
bit (7, E, 1), while RTU mode is
8 bits, even bit, 1 stop bit (8, E,
1). 6 types of baud rate:
b0: 4,800 bps (bit/sec)
b1: 9,600 bps (factory setting)
b2: 19,200 bps (bit/sec)
b3: 38,400 bps (bit/sec)
b4: 57,600 bps (bit/sec)
b5: 115,200 bps (bit/sec)
b6 ~ b13: reserved
b14: exchange low and high
byte of CRC check code (only
for RTU mode)
b15: ASCII/RTU selection
-- X R/W
DVP06PT-S:
CH5~CH6
Reset to default setting
And Error LED indicator
setting
b15~12 b11~9 b8~6 b5~3 b2~0
ERR
LED
reserved
CH6 CH5
If b2~b0 are set to 100, all the
setting values of CH5 will be
reset to the default settings. To
reset CH5 and CH6 to default
settings, set b5~b0 to H’24.
b12~13 correspond to CH5~6,
when bit is ON, the scale
exceeds the range, and the Error
LED indicator flashes.
#33 H’4085 O R/W
DVP04PT-S:
CH1~CH4
Reset to default setting
b15~12 b11~9 b8~6 b5~3 b2~0
ERR
LED
CH4 CH3 CH2 CH1
To Next Page
