Page #4 background imageLoading...
Page #4 background image
- 3 -
DVP06PT-S Celsius (°C) Fahrenheit (°F)
Overall accuracy
0.6% of full scale during 0 ~ 55°C (32 ~ 131°F)
Response time DVP04PT-S: 200ms/channel; DVP06PT-S: 160/ms/channel
Isolation method
Isolation between digital and analog circuitry. There is no isolation
between channels.
500VDC between digital circuits and Ground
500VDC between analog circuits and Ground
500VDC between analog circuits and digital circuits
500VDC between 24VDC and Ground
Digital data format 2’s complement of 16-bit
Average function Yes (DVP04PT-S: CR#2 ~ CR#5 / DVP06PT-S: CR#2)
Self diagnostic function Every channel has the upper/lower limit detection function.
RS-485 Communication
Mode
Supported, including ASCII/RTU mode. Default communication
format: 9600, 7, E, 1, ASCII; refer to CR#32 for details on the
communication format.
Note1: RS-485 cannot be used when connected to CPU series
PLCs.
Note2: The communication format can only be changed via
RS-485 and cannot be changed via the instruction TO while
connected to CPU series PLCs. Refer to Communication Format
Setup in the appendix of the DVP programming manual for more
details.
Control Register
CR# Address Latched Attribute Register content Description
#0 H’4064 O R
Model name
(Set up by the system)
DVP04PT-S model code= H’8A
DVP06PT-S model code = H’CA
#1 H’4065 X R/W CH1~CH4 Mode setting
b15~12 b11~8 b7~4 b3~0
CH4 CH3 CH2 CH1
Take CH1 mode (b3,b2,b1,b0)
for example.
1. (0,0,0,0): Pt100 (default)
2. (0,0,0,1): Ni100
3. (0,0,1,0): Pt1000
4. (0,0,1,1): Ni1000
5. (0,1,0,0): LG-Ni1000
6. (0,1,0,1): Cu100
7. (0,1,0,0): Cu50
8. (1,1,1,1): The channel is
disabled.
#2
H’4066
O R/W
DVP04PT-S:
CH1 average number
Number piece of readings used
for the calculation of “average”
temperature on CH1.
Setting range: K1~K20.
Default setting is K10.
--
DVP06PT-S:
CH1~CH6 average
number
Number piece of readings used
for the calculation of “average”
temperature on CH1 ~ 6.
Setting range: K1~K20.
Default setting is K10.
#3 H’4067 O H’4067
DVP04PT-S:
CH2 average number
Number piece of readings used
for the calculation of “average”
temperature on CH2.
Setting range: K1~K20.
Default setting is K10.
#4 H’4068 O H’4068
DVP04PT-S:
CH3 average number
Number piece of readings used
for the calculation of “average”
temperature on CH3.
Setting range: K1~K20.
Default setting is K10.
#5 H’4069 O H’4069
DVP04PT-S:
CH4 average number
Number piece of readings used
for the calculation of “average”
temperature on CH4.
Setting range: K1~K20.
Default setting is K10.
#6 H’406A X R CH1 average degrees
DVP04PT-S:
Average degrees for CH1 ~ 4
#7 H’406B X R CH2 average degrees
